0.5P energy storage pack is widely used in energy-requiring applications.
Configuration | 1P36S | 1P52S | 1P104S | |
Nominal Voltage | 115.2V | 166.4V | 332.8V | |
Voltage Range | 100.8~129.6V | 145.6~187.2V | 291.2~374.4V | |
Nominal Capacity | 330Ah | 314Ah | 314Ah | |
Charging/Discharging Rate | 0.5P/0.5P | 0.5P/0.5P | 0.5P/0.5P | |
Nominal Energy | 38.016kWh | 52.25kWh | 104.5kWh | |
Dimension | L1060*W830*H195 | L1170*W800*H245 | L2100*W800*H245 | |
Weight | 280kg | 330kg | 650kg | |
Energy Density | 135Wh/kg | 158Wh/kg | 160Wh/kg | |
BMS | Triple-level manage system, CAN | |||
TMS | Liquid Cooling | |||
Temperature | Charging | 0~+50℃ | ||
Discharging | -20~+50℃ | |||
Protection Level | IP67 | |||
